How to Add a Light Kit to Your Ceiling Fan

Ceiling fan keeping you cool but leaving you in the dark? Don’t worry, you aren’t stuck replacing your whole fan. For those with inadequate, single bulb lighting or lacking a light fixture altogether, adding a ceiling fan light kit offers a simple and inexpensive solutions to limited lighting.

Where can I pick up a ceiling fan light kit?

Ceiling fan light kits are available from your local home improvement chain, and typically cost only around $20 to $50 depending on the fixture type and features. Just be sure to measure the attachment point (the diameter of the opening) on your ceiling fan assembly before you go, so you don’t end up standing in the aisle scratching your head. Jotting down the company name and style/model number of your fan should simplify this task.

Can I do it myself?

Adding a ceiling fan light kit is a relatively simple DIY project. All you need is a light kit and a Phillips head as well as a slotted screwdriver.

How do I install a ceiling fan light kit?

  1. Turn off electricity to the fan at the breaker or fuse box. Turning off the entire panel is recommended to ensure safety. Double-check the fan is off by attempting to turn it on.
  2. Before removing your fan, ensure it has a housing assembly at its center, which can be hidden with an embellished cover or décor. If you have no housing assembly, you will NOT be able to add a ceiling fan light kit.
  3. Remove the ceiling fan for installation via tabletop for ease-of-access, or if you’re feeling brave and extra-coordinated, install it while standing on the stepladder.
  4. Remove the screws hanging below the fans center holding on the decorative center plate, then remove the plate to expose the wiring. Be certain to keep careful track of parts set aside. You should not need the cap, but you may need the screws.
  5. On most fans, dedicated wiring for a ceiling fan light kit will be visible and labeled “lighting power” or something similar. You are looking for 2 wires: A white (neutral) and a black (power) wire that will correspond with the wires on your new light assembly.
  6. Feed the light fixtures white and black wires through the hole in the center plate. Line up the matching wires so they are parallel, then screw on a wire nut to each set: White to white; black to black. The light fixture is now wired.
  7. Screw the light assembly onto the center plate of the fan, ensuring it is firmly attached.
  8. Re-attach the center plate to the fan body, replacing the screws that hold the center plate in place.
  9. Install light bulbs, shades, and pull chains as instructed by the manufacturer.
  10. Re-install the fan onto the ceiling, then turn the electricity to fan back on to check your work.

A little outside your comfort zone? Mr. Electric®  is here to help. Contact us today.
